Description
Features of this CNC machining center model:
- High quality control –perfect control system
-Laser inspection all based on VDI/DGQ 3441 standard.
-X/Y/Z axis positioning accuracy is controlled within 0.005/300.
-X/Y/Z axis repeatability is controlled within ±0.004mm.
-XY, YZ and ZX 2-axis contouring accuracy is controlled within 0.006mm.
-X/Y/Z axis acceleration can reach up to 11.2 m/s2(1.14G) or higher to reduce machining time and increase productivity. - High-speed precision spindle –12,000rpm
-Direct drive spindle: ensure tapping accuracy.
-Floating tool driving cylinder: prevent the bearing from impact force to maintain its accuracy and increase the life.
-Spindle 0-10,000 rpm accelerating time: 0.6 seconds.
-Spindle rigid tapping speed: 6,000 rpm.
-Maximum tapping size: M30.
-Example of maximum milling capability: S45C steel, 50mm diameter face milling cutter, 1.75mm cutting depth, iron chip removal rate Q= 120cc. - Automatic tool changer system –high capacity tool magazine
-Tool magazine capacity: 20 (optional capacity: 30).
-Optimal tool change path: reduce tool change time.
-Tool preparation: reduce tool change time. - High-speed arm type tool changer –low inertia and impact
-Safe double arm design for high speed tool change.
-Minimum arm length design, reducing rotational inertia.
-Patented air pressure quick tool change device for high speed tool changing.
-Tool to tool time: 0.95 seconds.
-Chip to Chip time: 2.95 seconds.
-The buffer design between arm and tool holder prevent the impact or wearing on spindle during tool changing. - CNC controller –SIEMENS SINUMERIK 828D
-Equipped with the latest commonly used communication ports, like CF card, USB and RJ45 network ports.
-Easy maintenance: RV-RAM technology based data backup, no battery needed.
-Remote diagnosis: support remote manipulation and file transfer to achieve fast and convenient maintenance.
-“Fine surface” motion control technology: improve workpiece surface machining quality and meanwhile reduce processing time.
-Multistage machining mode selection: achieve high-efficiency machining, fast tapping and precision mold machining.
-Program GUIDE: reduce machining time and increase productivity.
-Easy Message (optional): access to machining status wherever you are by receiving text messages
